Introduction：
Supports full-featured DSP, with each channel allowing for free definition.
EQ: Optional 1-16 segments, delay, compression, feedback suppression, high and low pass, HR, limiter, expander, noise gate, signal generator, automatic mixer (threshold type, gain sharing type), matrix mixer.
Product Description
| Specifications | |
| Maximum signal level (balanced) | 18dBu |
| Frequency response | 20Hz-20kHz，+0.5dB |
| Impedance | 110Ω (balanced type) |
| Dynamic range | ≥110dB @+18dBu,A-weighted |
| Signal-to-noise ratio | ≥99dB@+4dBu |
| THD+N | <0.005%@1kHz,A-weighted |
| Connector | RJ45 and 2 XLR-M |
| Power supply | Class 802.3 af PoE |
| Sampling rate | 48kHz |
| Bit depth | 24bit |
| AES67 device latency | 1,2, 5, or 6ms (configurable using skwkaesm win) |
| Network transmission | AES67 RTP audio |
| Product dimensions (L x W x H) | 176x42.9x57.4mm/6.9x1.7x2.3in |
| Product weight | 0.3kg |
| 1 Inner box packaging dimensions (L x W x H) | 235x125x70mm=0.002m:/93x49x2.8in |
| 20-piece outer box packaging dimensions (L x W x H) | 490x270x385mm=0.051m:/193x10.6x15.2in |
