TS-33/TS-33A
Introduction:
TS-33 consists of a B&C 15”cone woofer and a 3”Nd magnetic HF compression driver. TS-33 features horn cabinet design, coaxial LF & HF, HF horn coverage 35°(H)*35°(V), 18mm plywood with slot-tongue structure for robust tone. The cabinet has 16 M10 flying points for quick and reliable suspension.
(5)
-
Features
> Horn design with strong directivity, high sensitivity, high SPL, far projection
> High performance speaker unit to extend frequency response, Nd magnetic HF
> Compact structure, coaxial HF&LF to delete sound interference
> Symmetrical trapezoidal enclosure for system installation
> Constant directivity horn for even frequency response
> NEUTRIK connector
-
Specification
Model TS-33 TS-33A Type 15” two way passive loudspeaker 15” two way active loudspeaker Frequency response 130Hz~18kHz(±3dB) 130Hz~18kHz(±3dB) 100Hz~20kHz(-10dB) 100Hz~20kHz(-10dB) Input Sensitivity(1m/1W) - 0dBu Sensitivity(1W@1m) 104dB(LF) ; 110dB(HF) - Amp power LF: 700W (continuous); 2800W(peak) LF: 1550W HF: 110W(continuous); 440W(peak) HF: 200W Nominal Impedance LF: 8Ω; HF: 16Ω - Coverage(HxV) 35°x35° 35°x35° Crossover 950Hz 950Hz Woofer 1X15”cone woofer/100mm voice coil 1X15”cone woofer/100mm voice coil HF driver 1X 75mm HF compression driver (1.4”throat) 1X 75mm HF compression driver (1.4”throat) / 75 mm voice coil / 75 mm voice coil Max SPL(@1m) 139dB(LF) ; 137dB(HF) 139dB (LF) ; 136dB(HF) Connector 2XSPEAKON XLR Dimension(WxHxD) 610x660x830(mm) 610x660x830(mm) Net weight 54kg 59kg
-
