WI08B/WI08W
Introduction:
Soundking WI08 series PA system is equipped with 8”speaker, plastic enclosure, two built-in 4.5Ah batteries(charging 4-6 hours, operating for more than 4 hours), MP3with USB/SD card port, LCD, mic input, reverb effect, classD power amplifier and mixer. The product features multi-function, high quality performance, high cost performanceratio. WI08B has bluetooth, and WI08W has WIFI Audio to receiveplayer signal, e.g. cell phone.
Applications:
Small sized party, dancing hall, outdoors activities, etc;
Soundking WI08 series PA system is equipped with 8”speaker, plastic enclosure, two built-in 4.5Ah batteries(charging 4-6 hours, operating for more than 4 hours), MP3with USB/SD card port, LCD, mic input, reverb effect, classD power amplifier and mixer. The product features multi-function, high quality performance, high cost performanceratio. WI08B has bluetooth, and WI08W has WIFI Audio to receiveplayer signal, e.g. cell phone.
Applications:
Small sized party, dancing hall, outdoors activities, etc;
(5)
-
Features
WI08B
> MP3 with USB/SD card port
> Bluetooth to play audio source from cell phone, etc;
> Mic input
> Reverb effect
> Built-in 9Ah-12V battery to work 4 hours
> 12V recharging port
> 220V power supply
> Output power 50W, 8” speakerWI08W
> MP3 with USB/SD card port
> WIFI audio to play audio source from cell phone, etc;
> Mic input
> Reverb effect
> Built-in 9Ah-12V battery to work 4 hours
> 12V recharging port
> 220V power supply
> Output power 50W, 8” speaker
-
Specification
Item Test condition Test data Rated power （1KHz，THD+N≤1﹪）/8Ω AC 220V 80W (±5%) Frequency response 20Hz--20 KHz（ 1W 8ohm ） ±0.5dB THD （1W，20Hz~20KHz） THD+N≤0.3﹪ EQ HI: 10K slope ±15dB (±2dB) MID:1.2KH peak LOW:80Hz slope Sensitivity MIC1(MIC1 volume to max, main volume to max） 10mV LINE(LINE volume to max, main volume to max） 110mV S/N ratio main volume to max(1KHz，8Ω A weighted) ≥85dB Protection Short circuit protection Max output OK Amp out DC protection ±2V Amp out overload protection support DC12V input reversed connection protection Support Limit protection ≥10dB Mic priority Release/press Press to activate Wireless mic freq 16 diversity UHF 600-900MHZ Mic efficient distance Radius(straight distance,wireless on) 20m Battery 12V 4.5AHx2 Amp Class D Noise <2mV(A weighted) Charging type Smart charging Charging time 10 h Standby time 8h Power consumption Static(charging) ≤55W rated(charging) ≤165W Contour Enclosure ABS+PP Front panel Al alloy Weight Net weight 20Kg Gross weight 24Kg Dimension 450*415*695 mm
-
