AGA Series
Introduction:
This series of products AGA1000/1600/2200/3500 are specially designed hi-power amplifier used for touring and installation. Their unique design and powerful output can meet the requirement of any sound reinforcement project.With high performance, innovative appearance, and high quality components, AGA series to ensure low noise and high power operation, Nichicom capacitor for wide dynamic operation, “ON” transistors for powerful bass and clear treble and for reproducing original sound, professional protection circuit for reliable operation.
Application:
Large/medium-scale stadium, entertainment venues, bar, theatre and cinema, large show etc.
This series of products AGA1000/1600/2200/3500 are specially designed hi-power amplifier used for touring and installation. Their unique design and powerful output can meet the requirement of any sound reinforcement project.With high performance, innovative appearance, and high quality components, AGA series to ensure low noise and high power operation, Nichicom capacitor for wide dynamic operation, “ON” transistors for powerful bass and clear treble and for reproducing original sound, professional protection circuit for reliable operation.
Application:
Large/medium-scale stadium, entertainment venues, bar, theatre and cinema, large show etc.
(5)
-
Features
> CLASS H circuit improves the power amplifier efficiency &stability and decrease temperature in operation;
> Comprehensive protection, e.g. short-circuit protection, Thermal protection, DC protection;
> Cooling fan with variable speed;
> Built-in Limiter function to prevent the power amplifier from distortion of over input;
> Stereo/mono/bridge selector.
-
Specification
MODEL AGA1000 AGA1600 AGA2200 AGA3500 Output Power 8Ω 2x310W 2x550W 2x780W 2x1200W Output Power 4Ω 2x500W 2x810W 2x1150W 2x1900W Output Power 2Ω 2x700W 2x1000W / / Bridge Output power 8Ω 1000W 1600W 2200W 3600W Bridge Output power 4Ω 1300W 1900W / / Input Sensitivity 0dBu(0.775V) Frequency Response (20Hz-20KHz)+0dB/-0.5dB S/N Ratio(A-weighted) 100dB THD at rated output power <0.1%(MBW=80kHz,1kHz) Crosstalk (A-weighted) <-75dB Damp Factor(1kHz 8Ω) >300 >400 >400 >400 Protection Audio Limiters,High Temperature,DC,Short Circuit,HF,Peak Current Limiters,Turn-on Delay Power Requirements 220~240AC 50/60Hz 110~120@220~240AC 50/60Hz Weight 19kg 22kg 23kg 37kg Dimension(W×D×H)mm 483x410x88 483x420x88 483x420x88 483x420x133.3
-
