MC-P Series
Introduction:
MC series compact mixers are developed with WIFI transmission technology, the maximum distance is 100m. Compared with Bluetooth and the infrared,WIFI can transmit better and further. All the mixers can connect with cell phone, Ipad, PC, home cinema, etc directly to receive signal and to play music. With the WIFI design, MC series mixers are the optimal product which can meet the requirement of SOLO or band performance.
Each of MC series mixers is equipped with 2 Class D power amplifier with the maximum output up to 1000W. The class D power amplifier ensures the high efficiency and the lowest heat dissipation. The perfect protections, e.g. over current protection, over voltage protection, thermal protection, ensure the reliability during operation.
Application:
the reinforcement of public address and indoors recording, e.g. movie/TV/music recording, or used in theater, dancing hall, bar, etc
MC series compact mixers are developed with WIFI transmission technology, the maximum distance is 100m. Compared with Bluetooth and the infrared,WIFI can transmit better and further. All the mixers can connect with cell phone, Ipad, PC, home cinema, etc directly to receive signal and to play music. With the WIFI design, MC series mixers are the optimal product which can meet the requirement of SOLO or band performance.
Each of MC series mixers is equipped with 2 Class D power amplifier with the maximum output up to 1000W. The class D power amplifier ensures the high efficiency and the lowest heat dissipation. The perfect protections, e.g. over current protection, over voltage protection, thermal protection, ensure the reliability during operation.
Application:
the reinforcement of public address and indoors recording, e.g. movie/TV/music recording, or used in theater, dancing hall, bar, etc
(5)
-
Features
> Built-in WIFI to receive/play
> 6-12 low noise wide dynamic mic pre-amp for selection
> +48V phantom power for condenser mic
> Built-in dual DSP of 16 programs
> Built-in USB record/play function
> 2x9 band graphic EQ
> 6x12 segment meter
> Gooseneck lamp for lighting
> Universal power supply AC120V/230V
> 4groups, 4auxes, 1 mono and L/R outputs
> Built-in power amplifier: 2×500W/4Ω
-
Specification
MODEL MC08P MC12P MC16P MC24P Mic Input 6 10 14 22 Stereo Input 4 4 4 4 Aux Output 2 2 2 2 Amp Power Output 2 2 2 2 Stereo L/R Output 2 2 2 2 Group L/R Output 4 4 4 4 Gain 70dBu Frequency Response ( 20Hz-20kHz ) ±1dB Equivalent Input Noise -125dB (unweighted) Output Level Max+26dBu (balance) Max+22dBu (unbalance) LF 80Hz±15dB MF ±15 dB (200Hz-5kHz) HI 12 kHz±15dB 2×9-Segment Graphic EQ Center Frequency 63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz,4 kHz, 8 kHz, 16 kHz Amp power 2×500W/4Ω Distortion ≤0.05dB% (20Hz-20kHz) Weight (kg) 14kg 17kg 20.5kg 25kg Dimension(WxDxH)mm 545x574x159 545x669x159 545x763x159 545x952x159
-
