PL21S
Introduction:
The loudspeaker features horn design, high sensitivity, high SPL, long projection distance, powerful subfrequency. When used with full range loudspeaker, the system bass can be extremely extended.
Applications:
Applications: subwoofer for live performance.
The loudspeaker features horn design, high sensitivity, high SPL, long projection distance, powerful subfrequency. When used with full range loudspeaker, the system bass can be extremely extended.
Applications:
Applications: subwoofer for live performance.
(5)
-
Features
> Horn design, high sensitivity, high SPL, long projection distance;
> 18mm plywood enclosure with slot/tongue structure;
> Black painting finish for durability.
-
Specification
Model PL21S Type 21” Passive subwoofer Frequency response 32Hz –150Hz(-10dB) Nominal Impedance 8Ω Rated power 1000W ( continuous), 4000W (peak) Sensitivity(1W@1M) 98dB Max. SPL 134dB Coverage (H*V) / Crossover (MF/HF) / Unit 1X21"/152mm voice coil Connector 2XNL4MP Dimension(WxHxD) 655x1339x798 (mm) Weight 130kg
-
