AS-EDC Series
Introduction:
This AS Series Mixer is an ideal audio equipment with fashionable appeal professional performance.built-in 2×9 graphic EQ and high quality DSP(32 prpgram,e.g.,hall,live show ,delay,reverb,etc.) class H power amplifier switch power,etc..
This AS Series Mixer is an ideal audio equipment with fashionable appeal professional performance.built-in 2×9 graphic EQ and high quality DSP(32 prpgram,e.g.,hall,live show ,delay,reverb,etc.) class H power amplifier switch power,etc..
(5)
-
Features
> 3 band EQ offers responsive control and mic channels include one frequency sweep controls
> 2×9 band graphic equaliser(R/L channels)
> 2 AUX sends and Built-in DSP effect
> 32 prpgram DSP
> 60mm fader (ALPS)
> AS1404GED/C 19"standard rack mounted
> 2×500W class H amplifier
-
Specification
MODEL AS1404GEDC AS1404CEDC AS1804CEDC AS2204CEDC Mic Input 10 10 14 18 Stereo AUX Input 4 4 4 4 Aux 2 2 2 2 DSP 32programs 32programs 32programs 32programs Stereo L/R Output 2 2 2 2 ALT-stereo OutPut 2 2 2 2 Gain 80dB(MIC main output) MIC CH. EQ±15dB HI: 12kHz, MID:500-5kHz,LO:60Hz Frequency response (20-20kHz)±1dB Equivalent input noise -125dB (unweighted) Maximum Output Level +26dBu Meter 12segment(-30dB to 18dB) Distortion ≤0.01%(20-20kHz) Lamp 1 Power amp output 2×500W(load 4ohm) class H amplifier Weight (kg) 15.5kg 15.7kg 16.5kg 18.5kg Dimension(mm) 484X410X150 490X410X150 590X410X150 696X410X150
-
