LE205S/LE205SA
Application:
Meeting room, multi-function hall, theatre,auditorium, church, etc
Meeting room, multi-function hall, theatre,auditorium, church, etc
(5)
-
Features
Necessary spares(Page20):
>Hanging line(1/ each string);
>Latch(6 /each one);
>Hanging top rack(1 /each string)
Optional Components(Page20-23):
>Electric hoist ;
>Flight case;
>DB076 speaker rack;
>Hanging rack. (LE205S)
-
Specification
Model LE205S LE205SA Type Subwoofer Active Subwoofer 50Hz~350Hz (-10dB) 50Hz~350Hz (-10dB) Frequency Response 55Hz~300Hz (±3dB) 55Hz~300Hz (±3dB) LF 2×10" ( 254mm ) /2.6" voice coil 2×10" ( 254mm ) /2.6" voice coil Sensitivity(1m/1W) 97dB 0dBu Nominal Impedance 4Ω / Power handling 250W x 2 (continuous) 1000Wx2 (peak) 750W(LF) x 750W(MF/HF) Max SPL(@1m) 130dB 130dB Crossover 80Hz 80Hz Dimension (WxHxD) 505×410×610(mm) 505×410×652(mm) Weight 30kg 33kg
-
