Products Catalog
KA215A
(5)
-
Features
> Cabinet adopts MDF, strong strength, and is very economical.
> Woofer adopts high temperature-resistant KAPTON voice coil frame, high efficient magnetic circuit design.
> Tweeter adopts aluminum diaphragm and PEN diaphragm, accurate phase corrector ensure the cleanness of high frequency .
> Accurately designed crossover network ensure the speaker’s sound quality can be reproduced truly.
> It sets build-in LC crossover with high frequency protection of low distortion.
> It features 12 M10 hanging system, convenient and safe hanging setting.
> Φ35mm bracket holes ensure the stability of product fixed installation.
-
Specification
Model KA215A Type 2x15 " active woofer Frequency response 40Hz-20kHz(-10dB) Sensitivity(1W@1m) -10dBv±1dBv Amp power rated 500W Crossover 2.2kHz LF 2x15" woofer 65 mm voice coil HF 44mm compression driver /1 inch exit Coverage(HxV) 80°x60° Max SPL 129dB Dimension(WxHxD) 471.7X1050X538(mm) Weight 54.7kg Bottom wheels for easy moving
-
