KA10A/KA12A/KA15A
(5)
-
Features
> Cabinet adopts MDF, strong strength, and is very economical.
> Woofer adopts high temperature-resistant KAPTON voice coil frame, high efficient magnetic circuit design.
> Tweeter adopts aluminum diaphragm and PEN diaphragm, accurate phase corrector ensure the cleanness of high frequency .
> Accurately designed crossover network ensure the speaker’s sound quality can be reproduced truly.
> It sets build-in LC crossover with high frequency protection of low distortion.
> It features 12 M10 hanging system, convenient and safe hanging setting.
> Φ35mm bracket holes ensure the stability of product fixed installation.
-
Specification
Model KA10A KA12A KA15A Type 10 " 2way active speaker 12 " 2way active speaker 15 " 2way active speaker Frequency response 60Hz-20kHz(-10dB) 50Hz-20kHz(-10dB) 45Hz-20kHz(-10dB) Sensitivity(1W@1m) -10dBV±1dBV -10dBv±1dBv -10dBv±1dBv Amp power rated 200W 250W 250W Crossover 2.0kHz 2.2kHz 2.0kHz LF 10" woofer 50 mm voice coil 12" woofer 65 mm voice coil 15" woofer 65 mm voice coil HF 34mm driver/1inch exit 34mm driver/1inch exit 34mm driver/1inch exit Coverage(HxV) 80°x60° 80°x60° 80°x60° Max SPL 121dB 123dB 123dB Dimension(WxHxD) 353.5x555x426(mm) 409x628x472 (mm) 452.6x710x518(mm) Weight 20.8kg 25.5kg 31.3kg
-
