Products Catalog
FHE12MB/FHE15MB
(5)
-
Features
> Elegant appearance, wearable, solid, water-proof wooden box.
> High performance tweeter and woofer, big power, excellent tone.
> Seven M10 flying points makes hanging flexible.
-
Specification
Model FHE12MB FHE15MB Type 12"Active Stage Monitor 15"Active Stage Monitor Frequency response 55Hz--20kHz(-10dB) 50Hz--20kHz(-10dB) LF 12"LF/75mm voice coil 15"LF/75mm voice coil HF Ti/PEN diaphragm /44mm voice coil Ti/PEN diaphragm /44mm voice coil Input Sensitivity 0dBu 0dBu Max.SPL 129dB 131dB Amp power rated 300W (LF)+80W (HF) 400W (LF)+80W (HF) Coverage(HxV) 90°×40° 90°×40° Crossover 2.0kHz 2.0kHz Input connectors JACK/XLR JACK/XLR Power supply 230V/115V 230V/115V Dimensions (WxHxD) 608×360×335 (mm) 696×415×386 (mm) Net weight 22kg 28.5kg
-
