FHE8A / FHE10A / FHE12A / FHE15A
(5)
-
Features
> The magnet configuration of woofer greatly reduces distortion. Winding voice coil increases the surface of voice coil and heat dissipation.
> High sensitivity, power and efficiency
> Tweeter with 3” and 1.74”voice coil, horn with constant directivity, rational power design, ensure legant tone and sufficient power margin.
> Water proof paint and grille with waterproof structure for the applications in various weather
> Fourteen M10 screws for hanging, standard pole mounting, quick set up, multi-angle hanging
-
Specification
Model FHE8A FHE10A FHE12A FHE15A Type 2- way 8” active loudspeaker 2- way 10” active loudspeaker 2- way 12” active loudspeaker 2- way 15” active loudspeaker Frequency response 65Hz~20kHz(-10dB) 55Hz~20kHz(-10dB) 45Hz~20kHz(-10dB) 40Hz~20kHz(-10dB) Max SPL 120dB 124dB 126dB 128dB Coverage(H*V) 90°x60°(rotatable) 90°x60°(rotatable) 90°x60°(rotatable) 90°x60°(rotatable) Crossover 3.0kHz 2.5kHz 1.8kHz 1.5kHz LF 8”MF/LF / 50mm Voice Coil 10”MF/LF / 75mm Voice Coil 12”MF/LF / 75mm Voice Coil 15”MF/LF / 75mm Voice Coil HF PK diaphragm / 44mm Voice Coil PK diaphragm / 44mm Voice Coil PK diaphragm / 44mm Voice Coil Ti / PEN diaphragm / 75mm Voice Coil Input connector JACK / XLR JACK / XLR JACK / XLR JACK / XLR Input sensitivity 0dBu 0dBu 0dBu 0dBu Amp power rated 200W(LF)+60W(HF) 300W(LF)+60W(HF) 350W(LF)+100W(HF) 400W(LF)+100W(HF) Dimension(WxHxD) 300x514x330(mm) 340x578x357(mm) 390x660x409(mm) 424x740x437(mm) Weight 18kg 21kg 26kg 36kg
-
