FC415/FC415A
(5)
-
Features
> 2-way cinema loudspeaker system, FC415A features built-in crossover, FC415 requires an external crossover.
> 1.5" throat neodymium compression driver equipped with a Φ75mm voice coil, and two 15” woofers with Φ75mm voice coil .
> High sensitivity, optimum directivity, high power, low distortion, true sound.
> Designed for small and medium cinema environments.
-
Specification
Model FC415 FC415A Type External 2way Speaker System Internal 2way Passive Speaker System Freq Response 35Hz～20KHz(±3dB) 35Hz～20KHz(±3dB) Impedance LF4Ω/HF8Ω 4Ω(4Ω/8Ω) Power LF 800W/HF 80W 900W Sensitivity(1W@1m) LF102dB/HF110dB 102dB(102dB/110dB) Max.SPL LF137dB/HF135dB 137dB Coverage 80°x40°(HxV) 80°x40°(HxV) Crossover 800Hz 800Hz Speaker unit 15" x2+3" x1 15" x2+3" x1 Dimension(W×H×D) 757x1267x450(mm) 757x1267x450(mm) Weight 73kg 74.5kg
-
