KCD210/KCD208
(5)
-
Features
> 10 inch (KCD210), 8 inch (KCD208) are the cinema surrounding loudspeakers;
> High power, high sensitivity, wide dynamic, low distortion to reproduce the original sound;
> Diamond shape, mutiple color to select for decoration;
> Paralleled design of the speaker to lift up the sound center; suitable for small/medium luxury cinema with limited height.
-
Specification
Model KCD210 KCD208 Type 2way 10" full range speaker 2way 8" full range speaker Freq response 48Hz –20kHz (-10dB) 51Hz –20kHz (-10dB) Sensitivity(1W@1m) 96dB 94dB Impedance 8Ω 8Ω Rated power/Max power 250W/1000W 150W/600W Crossover 1.8kHz 2.5kHz LF/HF 10" x 1 +Al mambrance /1.35" x 1 8" x 1 + Al membrance /1.35" x 1 Coverage 90°x60°(HxV) 90°x60°(HxV) Max.SPL 118dB(continuous)/124dB 116dB（continuous）/122dB Dimension(WxHxD) 660x480x374 580x390x310 Weight 13 kg 9 kg
-
