FCE412H-1
(5)
-
Features
> Two way surround speaker cabinet specially developed for 3D audio cinema (medium size)
> It consists of aφ75mm 12″ MFLF unit and aφ44mm compression HF driver. MFLF unit uses the latest developed cone to offer natural tone, powerful bass, clear vocal. The symmetric magnetic design keeps balanced magnetic flux and lower distortion. Al voice coil improves efficiency. HF driver uses T yoke with short circuit design to lower distortion, kapton diaphragm and Al voice coil to maximize the heat dissipation. All these ensure bright tone and stable performance.
> Equipped with stand adjustable horizontally and vertically
> Steel frame for reliable suspension
> High power/sensitivity/resolution, excellent directivity and low distortion to reproduce 3D audio.
-
Specification
Model FCE412H-1 Type Two Way 3D Audio Cinema Surround Speaker Cabinet Frequency 60Hz～20kHz Impedance 8Ω Rated power 400W Sensitivity (2.83v/1m) 98dB Max peak out 130dB Coverage (H*V) 120°x70° Crossover 2kHz Unit 12″x1+1.75″x 1 Compression Driver Dimension (WxHxD) 435x665x540mm Weight 19.5kg
-
