Products Catalog
FC715
(5)
-
Features
> 3 way speaker cabinet specially designed for 3D cinema.
> Two 100mm 15" LF unit; one 100mm Nd compression MF driver and one 100 Nd compression HF driver.
> High power/sensitivity/SPL; wide dynamic range; perfect tone; high resolution; fantastic directivity.
-
Specification
Model FC715 Type 3way 3 driver 3D cinema main speaker cabinet Freq Response 34Hz～20kHz (±3dB) impedance LF4Ω/MF8Ω/HF8Ω Power LF1400W/MF150W/HF120W Sensitivity(2.83v/1m) LF102dB/MF114dB/HF112dB Max.SPL LF139dB/MF142dB/HF139dB Coverage 100°x50°(HxV) Crossover 550Hz/1.8kHz LF unit 2x15" LF /4" voice coil MF unit 4" compression MF DRIVER/ND MAGNET HF unit 4" compression HF DRIVER/ND MAGNET Dimension(WxHxD) 820x2020x930mm Weight 105kg
-
